Product Overview
Advantages
We configure products to match the specific requirements of your intended usage environment.
A low-carbon, eco-friendly choice for modern green mobility.
Football Field Vehicle
This vehicle can accommodate 8–11 passengers and is designed for scenic area shuttle and transfer services.It features a flowing through taillight design combined with integrated headlights, giving it a sleek, dynamic and imposing appearance.The matching rear taillight design creates a cohesive and harmonious look at the front and rear.Seating options include bench seats, skin-absorbed foam seats, stitched leather seats and more, to meet diverse customer needs across different scenarios.
Key Features
01
Leaf spring
The electric reception car's ball cart adopts a single variable cross-section leaf spring, which has better shock absorption performance and is more comfortable.
02
Charger
The whole vehicle adopts an on-board charger, which is easy to install, easy to operate, and charging is safer and faster.
03
CONTROLLER
We specified AC model that are bundled with Charging protection and Anti Skipping regenerating braking to provide customers with more safety redundancy downhill riding.
04
rearview mirror
The entire vehicle can be equipped with a rearview mirror, which allows for easy visibility of oncoming vehicles while driving on the road, ensuring the safety of the driver and passengers.
Technical Specifications
|
Maximum Speed |
Forward:22km/h;Reverse:9km/h |
|
Grade Ability |
15%(≈8.5°) |
|
Turning Radius |
≤5.5m |
|
Dimension |
4200×1250×2000(mm) |
|
Wheelbase |
3300mm |
|
Track |
Front tire:880mm;Rear tire:1000mm |
|
Tay Load |
520kg |
|
Frame |
carbon steel integral frame |
|
Suspension |
Front Suspension: Macpherson independent suspension; Rear Suspension: Leaf spring and hydraulic shock absorbers |
|
Brakes |
Four-wheel hydraulic brakes system+Electronic parking brake(EM Brake) |
|
Battery |
Maintenance free battery/Lithium iron phosphate |
|
Drive Motor |
AC motor 5KW |
|
Controller |
48V AC controller |
Vehicle StructureVehicle Structure
Body
Chassis
Canopy
Front bumper
Rear
bumper
Floor assembly
Wheel
Suspension
Shock absorber
Steering system
Brake system
Brake disc
01
Cooler Box
Assembly
02
Sand Bottle
Assembly
03
Bag Rain
Cover
04
Luxury
Seats
Customization Services
Vehicle color
Logo printing
Battery type
Seat material
Roof design
Tire type
Seat color
Wheel rim style
Glass type
Headlight design
Frame material
Brake system
Applications
Golf Courses
1
>>
Resorts and Hotels
2
>>
Tourist Attractions
3
>>
Residential Communities
4
>>
Shuttle services
5
>>
Gated communities
6
Frequently Asked Questions
What material is the vehicle frame made of?
+
-
It Carbon steel.
What battery comes standard on the vehicle, and what other battery options are available?
+
-
The vehicle comes standard with maintenance-free lead-acid batteries; lithium iron phosphate batteries are also available as an option.
Are the seat colors customizable?
+
-
Customization is available according to customer requirements.
What is the vehicle's control system?
+
-
The vehicle is equipped with an AC control system.
