The electric ball picking cart has super strong driving ability, making it easy and effortless to pick up balls. Excellent MacPherson independent front suspension system, suitable for uneven terrain. High strength aluminum alloy integral frame, light weight, strong corrosion resistance. Lead acid maintenance free batteries save the cost of battery maintenance and improve customer efficiency. The customized painted steel wire frame protective net can maximize the safety of workers, making ball picking safer and faster.
The GREENMAN electric golf cart, which used to require staff to bend down and hike for long periods of time to pick up balls, is now being replaced by a nimble white figure - this is the newly introduced electric golf cart at the practice range. It not only brings significant improvement in work efficiency, but also writes a vivid footnote for the modernization and sustainable development of campus sports facilities management with its zero emission and low-noise "green figure".
Parameter
|
Maximum Speed |
Forward:22km/h;Reverse:9km/h |
|
Grade Ability |
40%(≈21.8°) |
|
Turning Radius |
≤3m |
|
Dimension |
2800×1250×1800(mm) |
|
Wheelbase |
1650mm |
|
Track |
Front tire:870mm;Rear tire:985mm |
|
Tay Load |
360kg |
|
Frame |
High strength aluminum /carbon steel integral frame |
|
Suspension |
Front Suspension: Macpherson independent suspension; Rear Suspension: Leaf spring and hydraulic shock absorbers |
|
Brakes |
Four-wheel hydraulic brakes system+Electronic parking brake(EM Brake) |
|
Battery |
Maintenance free battery/Lithium iron phosphate |
|
Drive Motor |
AC motor 4KW |
|
Controller |
48V AC controller |
