Mini Fire Fighting Truck

Mini Fire Fighting Truck
Details:
GREENMAN Mini fire fighting truck,Key units such as communities, streets, campuses, logistics parks, and factories should build fully functional micro fire stations, equipped with professional micro fire trucks, combat uniforms, gas and smoke masks, fire extinguishers, and other equipment. Establish a scientific management system, establish an emergency communication mechanism to assign responsibilities to individuals, and focus on improving the proactive prevention, self-examination, self correction, and self rescue capabilities of key units. To prevent fires to the greatest extent possible and extinguish initial fires to the greatest extent possible, truly achieving the goal of "extinguishing early, extinguishing small, extinguishing initial fires" and "arriving within 3 minutes" to extinguish initial fires.
Send Inquiry
Description
Send Inquiry

Product Features:



Mini fire fighting truck,High pressure fine water mist is suitable for emergency response to fires in enclosed spaces. The Greenman high-pressure fine water mist fire truck has a compact body and is suitable for driving through cities, neighborhoods, factories, and other areas. Fully enclosed body, automotive grade color coated paint process, with added UV resistant components to the paint surface; 48V/5kW AC motor, four-wheel hydraulic drum brake+electromagnetic brake, higher safety. The waterproof rating of the vehicle wiring harness is IP67. Intelligent charger, automatic power-off, overload protection.

Mini fire fighting truck



Parameter



Maximum Speed

Forward:22km/h;Reverse:9km/h

Grade Ability

20%(≈11.3°)

Turning Radius

≤3.5m

Dimension

3060×1230×2195(mm)

Wheelbase

2100mm

Track

Front tire:870mm;Rear tire:985mm

Tay Load

160kg

Frame

carbon steel integral frame

Suspension

Front Suspension: Macpherson independent suspension;

Rear Suspension: Leaf spring and hydraulic shock absorbers

Brakes

Front disc rear drum braking system

Battery

Maintenance free battery/Lithium iron phosphate

Drive Motor

AC motor 5KW

Controller

48V AC controller





Principle of fine water mist

The new high-efficiency fire extinguishing system uses pure water as the extinguishing medium and special high-pressure nozzles. Under specific pressure, the river water flow decomposes into small water droplets to extinguish the fire, with a dual fire extinguishing mechanism of high efficiency and suffocation.

product-384-254
product-364-253



shutter

Equipped with advanced rolling shutter door design, the entire cargo box can be sealed to ensure safety, aesthetics, and practicality.



Spray gun

High quality nozzle with excellent performance, dual use spray gun design for direct current and atomization, high pressure, long-range spray gun can be used to spray trees, shrubs, as well as clean small advertisements and dust.

product-376-250
product-728-486



BEEFED UP TRANSAXLE

The integrated pressure-die-casting aluminum gearbox housing is tightly sealed; Power is transmitted via mesh and involute teeth bevel gears, which generate steady output torque, lower noise and much better efficiency
